Liberty Pumps LCU-N220ST 230V Neutralizing Condensate Pump With Safety Switch and Tubing
Liberty Pumps LCU-N220ST Neutralizing Condensate Pump
The Liberty LCU-N220ST is a high-voltage neutralizing condensate pump designed for international and commercial applications requiring 230V power. It safely neutralizes acidic condensate from high-efficiency furnaces, boilers, and water heaters using a replaceable magnesium oxide media cartridge, while also handling non-acidic condensate from A/C units, dehumidifiers, or ice machines via dedicated inlet ports. With its built-in overflow safety switch and included 20 ft tubing, the LCU-N220ST provides a complete, code-compliant solution.
Key Features & Benefits
- 230V Power — suited for international installs and commercial systems requiring higher voltage.
- Neutralizer Cartridge — granular magnesium oxide media elevates pH of acidic condensate for safe disposal.
- Multiple Inlet Paths — three 1" inlets for non-acidic condensate; dedicated 1" and ¾" inlets for acidic lines.
- Overflow Safety Switch — protects against pump failure or blocked discharge lines.
- Removable Check Valve — simplifies maintenance and replacement.
- Compact & Quiet — thermally protected motor with vibration isolation pads.
- Includes 20 ft Tubing — flexible setup straight out of the box.
| Model | LCU-N220ST |
| Horsepower | 1/30 HP |
| Voltage / Current | 230 V, 0.7 A |
| Max Fluid Temperature | 150 °F (65.5 °C) |
| Max Lift / Head | 20 ft |
| Reservoir Capacity | 2 US quarts |
| Dimensions (H × L × W) | 6.5 × 19 × 5 |
| Weight | Approx. 11 lbs |
Applications & Use Cases
- Neutralizing acidic condensate from high-efficiency boilers, furnaces, or water heaters (up to 500,000 BTU input)
- Pumping non-acidic condensate from A/C units, dehumidifiers, and ice machines
- Commercial or international installations requiring 230V operation
Maintenance & Replacement
- Replace neutralizer media cartridge (part # K001898) annually or when condensate pH drops below safe levels.
- Inspect check valve, inlet fittings, and overflow safety switch during routine service.
- Always install with proper air gap and per local code for condensate drainage.
Specifications are subject to change. Always confirm installation and service details with the official Liberty Pumps documentation.
