Kichler - 310072SBK - Daya™ LED 54" Ceiling Fan Satin Black

Spec Sheet

The Daya™ 54 inch ceiling fan delivers LED light through Satin Etched Cased Opal Glass and features a Satin Black finish.

• Daya ceiling fans are ideal for both industrial and coastal interior settings.
• Daya delivers an energy efficient light through its beautiful Satin Etched Cased Opal Glass. Surrounded by an RLM cage, Daya exudes confidence and takes control.
• Daya's blades consist of a lightweight, durable plastic, which protects them against warping in moisture. Their unique variable blade pitch provides optimum air movement.
• Bring Daya's distinct design to your dining or family room.
• Integrated LED
• The Daya ceiling fan produces an ambient light to illuminate your entire room.
• What's in the box? (5) 54inch ABS fan blades, (1) 172mm x 20mm AC motor, (1) Mounting Kit, (1) Hanger System, (1) 4.5 inch Down rod, (1) LED module with Etched Cased Opal Glass, (1) 65K Wall Control System-Full Function

Cleaning instructions: Be certain the electric current is turned off before cleaning. Clean metal components with a soft cloth moistened with a mild liquid soap solution. Wipe clean and buff with a very soft dry cloth. Under no circumstances should any metal polish be used, as its abrasive nature could damage the protective finish placed on the metal parts. Never wash glass shades in an automatic dishwasher. Instead, line a sink with a towel and fill with warm water and mild liquid soap. Wash glass with a soft cloth, rinse and wipe dry.

Airflow:

• CFM (High): 5715
• CFM (Low): 2259
• RPM (High): 134
• RPM (Low): 56

Blade Finish & Specs:

• Blade Finish 1: Satin Black
• Blade Material: ABS

• Blade Pitch: 12
• Blade Sweep: 54
• Number of Blades: 5


Certifications/Qualifications:

• Title 20 Compliant: Yes

Dimensions:

• Downrod 1: 1.00 OD X 4.50"
• Base Backplate: 6.00 DIA

• Weight: 29.20 LBS

Electrical:

• Amps (High): 0.60
• Amps (Low): 0.27
• Motor Size: 172MM X 20MM

• Motor Type: AC Induction

Housing:

• Fan Primary Control System: 65K Cooltouch - Full Function
• Remote Included: Yes

• Diffuser Description: Etched Cased Opal
• Primary Material: Steel


Light Source:

• Downlight Included: Yes
• Downlight Option: Integrated
• Watts (High): 71

• Watts (Low): 15
• Dimmable: Yes
• Lamp Included: Integrated
• Light Source: LED
• # of Bulbs/LED Modules: 1
• Optional Light Kit Available: Integrated

Mounting/Installation:

• Interior/Exterior: Exterior

• Lead Wire Length: 78"
• Location Rating: Damp
• Mounting Style: Downrod
• Mounting Weight: 25.20 LBS

Photometrics:

• Color Rendering Index: 90
• Delivered Efficacy (Lumens/Watt): 80
• Kelvin Temperature: 3000K

Product/Ordering Information:

• Finish: Satin Black
