Franklin Electric 2824055015 Deluxe Control Box – ½ HP, 230V, 60 Hz

The Franklin Electric Deluxe Control Box (CRC Model) offers premium protection and start performance for ½ HP submersible motors. Designed for demanding well systems, it features replaceable components and a rugged enclosure for easy field service.

Features

• For ½ HP, 230V, single-phase 3-wire motors
• Heavy-duty start capacitor and relay for reliable operation
• High-impact weather-resistant housing
• Easy-access design for quick maintenance

Applications

• Residential and light commercial well systems
• Pressure and irrigation pumps

Ratings
Frequency	60 Hz
Phases	Single-Phase
Volts	230 VAC
Control Box Max Amps	4.3 A
Rating	1/2 hp / .37 kW
Control Box Nominal Amps	3.2 A
Hz	60 Hz
Input Phase	Single-Phase
Input Voltage	230 VAC
Control Box Type	CRC



Operation
Enclosure Rating	Type 3R
Minimum Operating Temperature	14 °F
Maximum Operating Temperature	122 °F
Storage Temperature	-13° to 144 °F (-25° to 65 °C)
