DIG Irrigation - 15-014 - .710" OD Coupling

Constructed of molded ultraviolet-resistant, high-impact plastic, DIG’s Compression Fittings are able to fit a range of polyethylene drip tubing and drip line sizes from 3/8 to 5/8; no tools, glues or clamps are required.

Features

• High-impact plastic
• Available to fit all sizes of drip irrigation tubing
• Wide range of configurations including hose-end pipe threads
• Color coded
• UV resistant
• Secure and easy installation without glue or clamps
• Fits all 16 and 17 mm drip line, and polyethylene drip tubing sizes with .450 OD, .620 OD, .670 OD, .700 OD and .710 OD”

Specifications

• Operating pressure: 60 PSI (4.2 BAR) *Color inserts:
  • .450" OD with red insert fits drip irrigation tubing with .450" OD to .480" OD
  • .620" OD with green insert fits drip irrigation tubing and 16 mm drip line with .610" OD to .640" OD
  • .670" OD with brown insert fits brown drip irrigation tubing and 17 mm drip line with .660" OD to .670" OD
  • .700" OD with black insert fits drip poly tubing with .680" OD, .700" OD and .704" OD
  • .710" OD with blue insert fits drip poly tubing with .710" OD to .720" OD
